| Feature | Value |
|---|---|
| Standart | IEC 61009-1 |
| Rated Current - In | 16 |
| Rated Residual Operating Current IΔn | 30 |
| Number of Poles (P: Phase, N: Neutral, FE: Functional Earth) | 1P+N |
| Operating Characteristic According to Current Type | AC |
| Rated Operating Voltage – Ue (V) | 230 |
| Rated Insulation Voltage – Ui | 500 |
| Rated Impulse Withstand Voltage – Uimp (kV) | 4 |
| Rated Short-Circuit Breaking Capacity (kA) | 10 |
| Protection Characteristic (Instantaneous Trip) | B / C |
| Operating Temperature | -25 / 60°C |
| Mounting | DIN ray 35mm |
| Mechanical Life | >20000 |
| Electrical Life | >5000 |
| Min–Max Connection Cross-Section (mm²) | 1-10 |
| Min–Max Tightening Torque (Nm) | 1-2 |
| Dimensions (Width x Length x Depth) | 18 x 92 x 74 |
