| Type | Value |
|---|---|
| Protection Class | Type 1+2 (B+C) |
| Max Continuous Operating Voltage Uc (L-N / N-PE) | 385 AC |
| Voltage Protection Level Up (L-N / N-PE) | <2,1 / 1,5 |
| Surge Current (10/350µs) (L-N / N-PE) | 5 |
| Max Discharge Current (8/20µs) | 50 |
| Rated Discharge Current (8/20µs) | 20 |
| Pole | 3P+N |
| Max Conductor Cross-Section (mm²) | 35 |
| Fuse or Switch (A) | ... |
| Alarm Contact | NO+NC |
| Dimensions (Width x Height x Depth) | 72x90x66 |
| Operating Temperature | ~40°C ... +85°C |
| Relative Humidity (25°C) | ≤ 95% |
| Mounting | DIN ray 35mm |
| Test Standard | IEC 61643-11 |
| Enclosure Material | Cam Elyaf Takviyeli Plastik |
