| Type | Value |
|---|---|
| Protection Class | Type 3 (D) |
| Max Continuous Operating Voltage Uc (L-N / N-PE) | 440 AC |
| Voltage Protection Level Up (L-N / N-PE) | <1,4 |
| Surge Current (10/350µs) (L-N / N-PE) | ... |
| Max Discharge Current (8/20µs) | ... |
| Rated Discharge Current (8/20µs) | ... |
| Pole | 1P+N / 3P+N |
| Max Conductor Cross-Section (mm²) | 25 |
| Fuse or Switch (A) | 32 |
| Alarm Contact | ... |
| Dimensions (Width x Height x Depth) | 36x90x66 (1P+N)\n72x90x66 (3P+N) |
| Operating Temperature | ~40°C ... +85°C |
| Relative Humidity (25°C) | ≤ 95% |
| Mounting | DIN ray 35mm |
| Test Standard | IEC 61643-11 |
| Enclosure Material | Cam Elyaf Takviyeli Plastik |
